SKU: WSZC80-JCS
JCS WSZC80 Zinc Plated Steel Hi-Grip Wing Screw Adjustment Range 60-80mm Band Width 13mm
JCS WSZC80 Zinc Plated Steel Hi-Grip Wing Screw Adjustment Range 60-80mm Band Width 13mm
Regular price
$10.29
ex VAT
Regular price
Sale price
$10.29
ex VAT
In stock
Price Break
10+
$9.16
19+
$8.64
29+
$8.54
39+
$8.44
49+
$8.33
74+
$8.23
99+
$7.72
199+
$7.61
249+
$7.51
499+
$7.41
999+
$7.20
Couldn't load pickup availability
Description
Description
Zinc Plated Steel Hi-Grip Wing Screw: Specifically designed for frequently removed hoses, the unique dovetail locking and side lugs of the wing plate ensure excellent sealing and longevity. Used for a wide variety of domestic, automotive and industrial applications, the standard Hi-Grip hose clip is made from mild steel, electroplated, passivated and tested to EN9227. Hi-Grip general-purpose worm drive hose clips are widely regarded for their quality, durability and ability to withstand a great deal of abuse.
- Brand / Quality:
- JCS - High Quality
- Width:
- 13mm
- Min Adjustment Range:
- 60mm
- Max Adjustment Range:
- 80mm
Technical
Technical
| BS No. | 80 |
|---|---|
| Adjustment Range (mm) | 60-80mm |
| Adjustment Range (inch) | 2-3/8 - 3-1/8 inch |
| A | 13mm |
| B | 37mm |
| C | 12mm |
| D | 16mm |
| E | 13mm |
| F | 0.9mm |
| G | 24mm |
| Recommended Torque Nm | 6Nm |
| Recommended Torque lb-in | 54lb-in |
