Hose Fittings

These hose fittings are commonly used in hydraulic systems, to connect hoses to machinery and cylinders under high pressure.

84 products

Loading filters…

Hose Fittings

What is a hydraulic hose fitting?

A hydraulic hose fitting is the metal connector attached to the end of a hydraulic hose that allows it to be joined to a pump, valve, cylinder, motor, pipe, or another hose. Hydraulic systems use pressurised fluid, usually oil, to transmit power, and hose fittings make the connections that keep that fluid flowing safely without leaking. Because hydraulic systems often work at very high pressures, fittings must be strong, precisely made, and correctly matched to both the hose and the port they connect to.

A typical crimped hydraulic hose fitting is made up of three main parts:

  • Insert (also called the stem or tail): the part that slides inside the hose and has ridges or barbs to grip the inner tube.
  • Ferrule (also called the shell or socket): a metal sleeve that fits over the outside of the hose and is crimped or swaged to clamp the hose firmly onto the insert.
  • Connection end: the threaded nut, male thread, flange, or other termination that connects the hose assembly to the rest of the system.

Key features:

  • High pressure capability: designed to hold pressures ranging from a few hundred psi up to 6,000 psi (about 420 bar) or more, depending on type and size.
  • Leak-tight sealing: sealed by metal-to-metal contact, O-rings, bonded seals, or thread sealing, depending on the design.
  • Wide range of thread standards: including BSP, JIC, ORFS, metric DIN, NPT, SAE, and JIS.
  • Many shapes: straight, 45-degree, 90-degree, banjo, flange, and other configurations to suit routing and space.
  • Permanent or reusable designs: crimped fittings for permanent assemblies, and field-attachable fittings that can be fitted without a crimping machine.
  • Durable materials: usually carbon steel with corrosion-resistant plating, with stainless steel and brass versions for special conditions.
  • Size range: from small fittings for 1/8 inch hoses up to large fittings for 2-inch hoses and beyond.

In simple terms, a hydraulic hose fitting is the secure, pressure-tight connection that turns a length of hydraulic hose into a working part of a hydraulic system.

Why are hydraulic hose fittings essential?

Hydraulic hose fittings are essential because the whole hydraulic system depends on safe, leak-free connections. A hose can only transfer fluid and power if its ends are securely attached and sealed. A poor, worn or mismatched fitting can leak, blow off under pressure, let contamination in or cause the system to lose power. In high-pressure systems, a failed fitting can also be a serious safety hazard.

Their main benefits are:

  • Safe pressure containment: correctly chosen and assembled fittings hold high system pressures securely.
  • Leak-free performance: good sealing prevents fluid loss, reduces mess, and protects the environment.
  • Efficient power transfer: tight connections keep pressure and flow where they are needed, maintaining machine performance.
  • Flexible system design: a huge range of shapes, sizes, and threads lets hoses be routed around tight spaces and connected to many different components.
  • Easy maintenance: hose assemblies can be removed and replaced without disturbing the rest of the system.
  • Contamination control: well-sealed fittings keep dirt and water out of the hydraulic fluid, protecting pumps, valves and cylinders.
  • Compatibility across equipment: standardised thread types allow fittings to be matched to machines from different manufacturers and countries.
  • Durability: strong materials and corrosion-resistant plating help fittings survive vibration, pressure spikes and harsh environments.

These qualities make hydraulic hose fittings important in a wide range of industries and equipment, including:

  • Construction machinery: excavators, loaders, dumpers, cranes, telehandlers and piling rigs.
  • Agricultural machinery: tractors, loaders, sprayers, balers, harvesters and trailers.
  • Industrial machinery: presses, injection moulding machines, machine tools and production lines.
  • Material handling: forklifts, lifting platforms, scissor lifts and conveyors.
  • Mining and quarrying: drilling rigs, crushers, haul trucks and underground equipment.
  • Transport and commercial vehicles: tipper trucks, refuse vehicles, tail lifts and cranes.
  • Forestry: harvesters, forwarders, log splitters and timber cranes.
  • Marine and offshore: winches, steering systems, deck machinery and offshore equipment.
  • Waste and recycling: compactors, balers and shredders.
  • Aerospace and defence: ground support equipment and specialised hydraulic systems.

By thread and connection standard:

  • BSP (British Standard Pipe): very common in the UK, Europe and Asia. BSPP (parallel) fittings usually seal with a 60-degree cone seat or a bonded seal, while BSPT (taper) fittings seal on the thread.

By shape and configuration:

  • Straight fittings: the most common shape for simple, direct connections.
  • 45-degree elbows: for gentle changes in direction.
  • 90-degree elbows: for tight spaces and sharp changes in direction, in standard, compact, and long-drop versions.
  • Female swivel fittings: have a rotating nut, allowing the hose to be connected without twisting.
  • Male fittings: screw directly into ports or female connectors.
  • Banjo fittings: hollow ring fittings secured with a hollow bolt, ideal for compact connections.
  • Flange fittings: straight or angled heads for SAE flange connections.
  • Tee and multiple outlet fittings: used for branching lines.

Related components:

  • Hydraulic adaptors: connect fittings and ports with different thread standards or sizes.
  • Quick release couplings: allow hoses to be connected and disconnected quickly without tools, such as ISO 7241 and flat face ISO 16028 types.
  • Bonded seals: metal and rubber washers used to seal BSPP and metric parallel threads.
  • O-rings: used in ORFS, ORB, DKO and flange connections.
  • Hose protection: spring guards, sleeves and covers to protect hoses and fittings from abrasion and damage.

By material:

  • Carbon steel: the standard material, usually zinc or zinc-nickel plated for corrosion protection.
  • Stainless steel: for marine, offshore, food-processing, chemical, and corrosive environments.
  • Brass: for some lower-pressure applications and specific fluids.

How to choose the right hydraulic hose fitting?

Choosing the right hydraulic hose fitting is critical for safety and performance. A widely used approach in the hydraulics industry is the STAMP method, which stands for Size, Temperature, Application, Media, and Pressure. Work through these points in order:

  • Size: match the fitting to the hose inside diameter, which is usually given as a dash size in sixteenths of an inch. For example, -4 is 1/4 inch, -6 is 3/8 inch, -8 is 1/2 inch, -12 is 3/4 inch, and -16 is 1 inch. Also identify the thread size of the connection end.
  • Temperature: check that the fitting, its seals, and the hose can handle both the fluid temperature and the surrounding temperature.
  • Application: consider vibration, movement, routing, space limitations, bending, and the type of machine. Choose angled fittings or swivels to avoid twisting and tight bends in the hose.
  • Media: check that the fitting material and seals are compatible with the fluid, whether mineral oil, biodegradable oil, water glycol, fuel or another fluid.
  • Pressure: make sure the fitting’s pressure rating meets or exceeds the system’s maximum working pressure, including pressure spikes. The whole hose assembly is only as strong as its weakest component.
  • Thread type: identify the connection standard correctly. Use a thread gauge, calipers, and a seat angle gauge to measure the thread diameter, pitch, and sealing angle, as many threads look similar but are not compatible.
  • Sealing method: choose between metal-to-metal, O-ring face seal, bonded seal, or tapered thread sealing, depending on the port and the level of leak protection needed. ORFS fittings are a good choice where leak-free performance under vibration is critical.
  • Hose compatibility: make sure the fitting is designed for the exact hose type, such as EN 853 1SN or 2SN wire braided hose, or EN 856 4SP or 4SH spiral hose. Fittings and hoses should be from the same manufacturer or an approved combination.
  • Crimp specifications: always use the hose and fitting manufacturer’s crimp diameter and crimping equipment settings.
  • Shape and orientation: choose straight, 45-degree, or 90-degree fittings, and check the orientation of angled fittings at both ends to avoid twisting the hose.
  • Material and plating: choose zinc or zinc-nickel-plated steel for general use, and stainless steel for corrosive or marine environments.

Essential references and hydraulic hose fitting ranges

Hydraulic hose fitting references vary between manufacturers, but they usually describe the connection type, shape, thread size, and hose size. Understanding the common size systems makes identification much easier.

Hose dash sizes (hose inside diameter):

  • -4: 1/4 inch, about 6.4 mm (DN6)
  • -6: 3/8 inch, about 9.5 mm (DN10)
  • -8: 1/2 inch, about 12.7 mm (DN12)
  • -10: 5/8 inch, about 15.9 mm (DN16)
  • -12: 3/4 inch, about 19 mm (DN19 or DN20)
  • -16: 1 inch, about 25.4 mm (DN25)
  • -20: 1 1/4 inch, about 31.8 mm (DN31 or DN32)
  • -24: 1 1/2 inch, about 38.1 mm (DN38 or DN40)
  • -32: 2 inch, about 50.8 mm (DN51 or DN50)

Common JIC 37-degree thread sizes:

  • -4: 7/16-20 UNF
  • -6: 9/16-18 UNF
  • -8: 3/4-16 UNF
  • -10: 7/8-14 UNF
  • -12: 1 1/16-12 UN
  • -16: 1 5/16-12 UN

Common ORFS thread sizes:

  • -4: 9/16-18 UNF
  • -6: 11/16-16 UN
  • -8: 13/16-16 UN
  • -10: 1-14 UNS
  • -12: 1 3/16-12 UN
  • -16: 1 7/16-12 UN

Common BSP thread sizes (nominal size and threads per inch):

  • 1/4 inch: 19 threads per inch
  • 3/8 inch: 19 threads per inch
  • 1/2 inch: 14 threads per inch
  • 3/4 inch: 14 threads per inch
  • 1 inch: 11 threads per inch

Common metric DIN 24-degree cone sizes (tube outside diameter and thread):

  • Light series: 06L (M12 × 1.5), 08L (M14 × 1.5), 10L (M16 × 1.5), 12L (M18 × 1.5), 15L (M22 × 1.5) and 18L (M26 × 1.5).
  • Heavy series: 06S (M14 × 1.5), 08S (M16 × 1.5), 10S (M18 × 1.5), 12S (M20 × 1.5), 16S (M24 × 1.5) and 20S (M30 × 2).

Common hose standards that fittings are matched to:

  • EN 853 1SN and 2SN: one-wire and two-wire braided hoses, the most common for general hydraulics.
  • EN 857 1SC and 2SC: compact braided hoses with tighter bend radii.
  • EN 856 4SP and 4SH: four-wire spiral hoses for high-pressure applications.
  • EN 856 R12 and R13: spiral hoses for very high pressure and heavy-duty applications.
  • SAE 100R series: American hose standards, such as 100R1, 100R2 and 100R12.

How fitting references usually work:

  • Most manufacturers build their part numbers from a series code, a connection type code, a shape code, a thread size, and a hose size. For example, a reference might describe a JIC female swivel 90-degree fitting with an -8 thread for a -8 hose.
  • Because each manufacturer uses its own coding system, it is important to check the catalogue for the exact meaning of each part of the reference.

Before ordering, always confirm the connection type, thread size, seat angle, shape, hose size, and hose type. When in doubt, measure the existing fitting with a thread gauge and calipers, or take it to a hydraulic hose specialist for identification.

FAQ: all you need to know about hydraulic hose fittings

What is the difference between BSPP and BSPT?

BSPP has a parallel thread and seals using a 60-degree cone seat, a bonded seal, or an O-ring. BSPT has a tapered thread that seals on the thread itself. They are not designed to be mixed.

What is the difference between JIC and ORFS fittings?

 JIC fittings seal metal-to-metal on a 37-degree flare, while ORFS fittings seal with an O-ring on a flat face. ORFS fittings generally give better leak-free performance under high pressure and vibration.

How do I identify a hydraulic fitting thread?

 Measure the thread diameter with calipers, check the thread pitch with a thread gauge, and check the seat angle with a seat angle gauge. Then compare the results with a thread identification chart.

What does the dash size mean?

 The dash size shows the hose inside diameter in sixteenths of an inch. For example, -8 means 8/16 inch, or 1/2 inch.

Can I mix fittings and hoses from different manufacturers?

 It is not recommended unless the manufacturers confirm the combination is approved. Fittings are designed and tested for specific hoses, and mixing can lead to blow-offs and leaks.

Can crimped fittings be reused?

 No. Crimped fittings are permanent and should be discarded with the old hose. Field-attachable fittings can sometimes be reused if they are undamaged.

Should I use thread sealant or PTFE tape?

 Only on tapered threads such as NPT or BSPT, and even then with care, as loose tape can contaminate the system. Parallel threads and cone, O-ring or flare seals should not use tape or sealant.

Why is my hydraulic fitting leaking?

Common causes include incorrect tightening, damaged threads or sealing surfaces, worn or missing O-rings, mismatched fittings, poor crimping, vibration, or the wrong thread standard being used.

How tight should a hydraulic fitting be?

 Fittings should be tightened to the manufacturer’s recommended torque or the flats-from-finger-tight method. Overtightening can damage the seal or thread, while undertightening can cause leaks.

What is a bonded seal?

A bonded seal is a metal washer with a rubber sealing ring, used to seal parallel threads such as BSPP and metric connections against a flat port face.

What pressure can hydraulic fittings handle?

It depends on the type, size and design. Smaller fittings can often handle higher pressures than larger ones of the same type. Always check the manufacturer’s rating and make sure it meets the system’s maximum working pressure.

How often should hydraulic hose assemblies be replaced?

 There is no single interval, as it depends on use, pressure, temperature and environment. Hoses and fittings should be inspected regularly and replaced if there are leaks, cracks, abrasion, corrosion, bulging or damaged fittings. Some industries also set maximum service life limits.

Is a hydraulic leak dangerous?

Yes. Fluid escaping under high pressure, even from a pinhole, can penetrate the skin and cause serious injury. Never check for leaks with your hands; use a piece of card or wood, wear protective equipment, and seek urgent medical help if fluid is injected into the skin.

What is the difference between a hose fitting and an adaptor?

 A hose fitting is attached to the end of the hose, while an adaptor connects two threaded components, such as a hose fitting and a port with a different thread type.
