Aluminium Motors

What is an aluminium motor?

An aluminium motor is an electric motor with a frame made from aluminium alloy. Most are AC induction motors, available in three-phase and single-phase versions, used to drive pumps, fans, compressors, conveyors, gearboxes, and a wide range of light and medium-duty machinery. Aluminium makes the motor much lighter than an equivalent cast iron motor, while still giving a strong, corrosion-resistant body with excellent heat dissipation.

Like cast iron motors, aluminium motors are usually totally enclosed fan cooled, often shortened to TEFC. The internal parts are sealed inside the frame, and a fan on the back of the motor blows cooling air over the ribbed outer body. Aluminium conducts heat very well, helping the motor stay cool during operation.

Many aluminium motors also have removable feet, so the same motor can be converted between foot mounting and flange or face mounting, making them very versatile.

A typical aluminium motor has:

  • Aluminium frame - a lightweight, ribbed housing that protects the motor and carries heat away
  • Stator - the fixed copper windings that create a rotating magnetic field when supplied with power
  • Rotor - the rotating part inside the stator, connected to the output shaft
  • Shaft - transmits power to the driven machine through a coupling, pulley, or gearbox
  • Bearings - support the rotor and shaft, usually sealed deep groove ball bearings
  • Cooling fan and cowl - draw air over the frame to keep the motor cool
  • Terminal box - houses the electrical connections, and on single-phase motors may include capacitors

Aluminium motors are usually described by:

  • Power - the output power in kW, such as 0.37 kW, 1.1 kW, or 4 kW
  • Speed or poles - on a 50 Hz supply, a 2 pole motor runs at about 2,900 rpm, a 4 pole at about 1,450 rpm, a 6 pole at about 960 rpm, and an 8 pole at about 720 rpm
  • Frame size - the standard IEC frame size, such as 71, 80, 90S, or 100L
  • Mounting type - such as foot mounted, flange mounted, or face mounted
  • Supply - three-phase, such as 230/400 V, or single-phase, such as 230 V
  • Efficiency class - such as IE2, IE3, or IE4
  • Protection rating - such as IP55

Key features:

  • Lightweight - much lighter than cast iron motors, making handling and installation easier
  • Corrosion resistant - aluminium resists rust, suiting damp and outdoor environments
  • Excellent cooling - aluminium conducts heat well, helping keep the motor cool
  • Versatile mounting - removable feet on many motors allow foot, flange, or face mounting
  • Single-phase options - ideal where only a single-phase supply is available
  • Sealed design - totally enclosed construction keeps out dust and moisture
  • Standard dimensions - IEC frame sizes make replacement and interchange easier
  • Cost-effective - an economical choice for many light and medium-duty drives

In simple terms, an aluminium motor is a lightweight, corrosion-resistant electric motor that is easy to handle and ideal for powering pumps, fans, and general machinery.

Why are aluminium motors essential?

Aluminium motors are essential because many machines need a reliable, efficient motor that is easy to install and handle. For smaller and medium-sized drives, a heavy cast iron motor is often not necessary, and the lighter weight of an aluminium motor makes it easier to fit, especially on equipment where weight matters, such as mobile machinery, wall-mounted fans, or flange-mounted pumps and gearboxes.

Their main benefits are:

  • Easy handling - lighter motors are quicker and safer to lift, fit, and replace
  • Reduced weight on equipment - ideal for flange-mounted pumps, gearboxes, and mobile machinery
  • Corrosion resistance - aluminium frames perform well in damp and outdoor conditions
  • Efficient cooling - good heat dissipation helps protect windings and bearings
  • Flexible mounting - removable feet and flange options suit many different installations
  • Single-phase availability - suitable for homes, farms, and workshops without a three-phase supply
  • Energy savings - high efficiency motors reduce electricity costs
  • Cost-effective - an economical solution for light and medium-duty applications

Aluminium motors are used across a wide range of industries and applications, including:

  • Pumps - water, garden, pond, irrigation, and process pumps
  • Fans and blowers - ventilation, extraction, and air handling
  • Compressors - small air compressors and refrigeration units
  • Conveyors - light-duty belt and roller conveyors
  • Gearboxes and drives - flange-mounted gear motors and small drives
  • Agricultural equipment - fans, small mills, mixers, and augers
  • Workshops - bench grinders, saws, polishers, and small machine tools
  • Food and drink processing - mixers, pumps, and conveyors
  • HVAC systems - fans, pumps, and air handling units
  • Packaging and automation - light-duty drives and machinery

The main types of aluminium motors

Aluminium motors are usually grouped by supply, mounting type, speed, and efficiency class.

By supply:

  • Three-phase aluminium motors - the standard choice for industrial and commercial machinery, offering efficient and reliable operation
  • Single-phase aluminium motors - used where only a single-phase supply is available, such as homes, farms, and small workshops. They use capacitors to help start and run the motor
  • Capacitor start motors - give high starting torque for loads that are hard to start, such as compressors
  • Capacitor start and run motors - give good starting torque and smoother, more efficient running
  • Permanent split capacitor motors - suit easy-starting loads such as fans and small pumps

By mounting type:

  • Foot mounted (B3) - the motor bolts to a base, motor base, or slide rails using feet on the frame
  • Large flange mounted (B5) - a large flange with clearance holes allows the motor to bolt directly to pumps, gearboxes, and machines
  • Small face mounted (B14) - a smaller face with tapped holes, often used for compact gearboxes and pumps
  • Foot and flange mounted (B35) and foot and face mounted (B34) - combine feet with a flange or face for extra support
  • Convertible mounting - many aluminium motors have removable feet, allowing them to be converted between mounting types

By speed:

  • 2 pole motors - about 2,900 rpm, used for pumps, fans, and high-speed drives
  • 4 pole motors - about 1,450 rpm, the most common speed for general use
  • 6 pole motors - about 960 rpm, used for slower drives
  • 8 pole motors - about 720 rpm, used for low-speed drives

By efficiency class:

  • IE2 (high efficiency) - used for some applications and smaller motors
  • IE3 (premium efficiency) - widely required for many three-phase motors under current regulations
  • IE4 (super premium efficiency) - offers the lowest energy use and running costs

By duty:

  • Standard motors - for general continuous running
  • Inverter-duty motors - designed for use with variable speed drives
  • Brake motors - fitted with a brake to stop and hold the load when power is removed

How to choose the right aluminium motor?

Choosing the right motor means matching it to the driven machine, the power supply, and the operating conditions. Work through these points in order:

  • Supply - check whether you have a three-phase or single-phase supply, and choose a motor to suit
  • Power - choose a motor with enough power for the load, allowing a margin for starting and peak loads
  • Speed - choose the number of poles to suit the speed needed by the driven machine
  • Starting torque - for single-phase motors, choose a capacitor start or capacitor start and run motor for loads that are hard to start, such as compressors
  • Frame size - check the IEC frame size, especially when replacing an existing motor, so the mounting dimensions and shaft height match
  • Mounting type - choose foot, flange, face, or combined mounting to suit the machine
  • Shaft size - check the shaft diameter and length suit the coupling, pulley, or gearbox
  • Voltage - check the voltage and frequency match the supply
  • Efficiency class - choose an efficiency class that meets current regulations and reduces running costs
  • Protection rating - choose a suitable IP rating, such as IP55 for general use, or higher for wet or dusty environments
  • Duty cycle - consider whether the motor will run continuously or start and stop frequently
  • Environment - consider temperature, moisture, dust, and corrosive conditions
  • Aluminium or cast iron - choose aluminium for lighter weight and general use, or cast iron for heavy-duty, high-vibration, and harsh environments
  • Quality and brand - choose motors from reputable manufacturers for reliable performance and support

FAQ: all you need to know about aluminium motors

What is the difference between aluminium and cast iron motors?

Aluminium motors are lighter, resist corrosion well, and cool efficiently, making them ideal for light and medium-duty applications. Cast iron motors are heavier and more rigid, suiting heavy-duty, high-vibration, and harsh environments.

Are aluminium motors as reliable as cast iron motors?

Yes, for the right application. Aluminium motors are reliable for many general-purpose drives. For heavy shock loads, high vibration, or very harsh conditions, a cast iron motor may be a better choice.

Can I run an aluminium motor on a single-phase supply?

Yes, if it is a single-phase motor. Single-phase aluminium motors use capacitors to start and run, and are ideal for homes, farms, and workshops without a three-phase supply.

What is the difference between capacitor start and capacitor start and run motors?

Capacitor start motors use a capacitor only during starting, giving high starting torque. Capacitor start and run motors use one capacitor for starting and another for running, giving good starting torque and smoother, more efficient running.

What does convertible mounting mean?

Convertible mounting means the motor’s feet can be removed or repositioned, allowing the motor to be used as foot mounted, flange mounted, or face mounted.

What does TEFC mean?

TEFC stands for totally enclosed fan cooled. The motor is sealed to keep out dust and moisture, and an external fan blows air over the frame to cool it.

What does IP55 mean?

IP55 means the motor is protected against dust that could affect its operation and against low-pressure water jets from any direction.

What do the poles on a motor mean?

The number of poles sets the motor’s speed. On a 50 Hz supply, 2 pole motors run at about 2,900 rpm, 4 pole at about 1,450 rpm, 6 pole at about 960 rpm, and 8 pole at about 720 rpm.

Can aluminium motors be used outdoors?

Yes. Aluminium resists corrosion well, and motors with a suitable IP rating can be used outdoors. Protect the motor from direct heavy rain and standing water where possible.

How do I look after an aluminium motor?

Keep the cooling fins and fan cowl clean, check the mounting bolts and alignment, monitor for unusual noise, vibration, or heat, and replace bearings when they show signs of wear.

Why won’t my single-phase motor start?

Common causes include a failed start capacitor, a faulty centrifugal switch, low supply voltage, or a load that is too heavy to start. Electrical faults should always be checked by a qualified electrician.
