Agricultural Bearings

These agricultural bearings are commonly used in tractors, balers and ploughs, to keep shafts turning smoothly under muddy, wet field conditions.

185 products

Loading filters…

Agricultural Bearings

What is an agricultural bearing?

An agricultural bearing is a bearing specially designed to withstand the tough conditions found in farm machinery. Unlike standard industrial bearings, which usually work in clean, controlled environments, agricultural bearings must survive dust, mud, water, crop residue, fertilisers, chemicals, shock loads, and long periods of inactivity between seasons. To cope with this, they are built with heavy-duty seals, robust housing, special greases, and features that make mounting simple and maintenance minimal.

The term “agricultural bearing” covers a whole family of products rather than a single design. Many are based on familiar bearing types, such as deep groove ball bearings, tapered roller bearings, or insert bearings, but they are adapted with extra protection and special bore shapes to suit agricultural equipment.

Common agricultural bearing designs include:

  • Disc harrow bearings - heavy-duty ball bearings, often with square or round bores, used on the gangs of disc harrows and tillage equipment
  • Insert bearings (Y-bearings) - ball bearings with a spherical outer ring and an extended inner ring, designed to fit into housings and lock directly onto the shaft
  • Bearing units - insert bearings supplied ready-mounted in cast iron, pressed steel or polymer housings, such as pillow blocks and flanged units
  • Hub units - pre-assembled, sealed and greased wheel or disc hub assemblies for tillage equipment, seed drills, and trailers
  • Square and hex bore bearings - bearings with square or hexagonal bores that slide directly onto matching shafts, transmitting drive without keys or set screws
  • Special tillage and planter bearings - designed for specific machines such as seed drills, planters, cultivators, and balers

Key features:

  • Heavy-duty sealing - multi-lip seals, flingers, and shields to keep out soil, dust, water, and crop residue
  • Self-aligning - many designs have a spherical outer surface to tolerate shaft misalignment and frame flexing
  • Special bores - square, hexagonal, or round bores for simple mounting on agricultural shafts
  • High shock resistance - robust construction to withstand impacts from stones, uneven ground, and heavy loads
  • Lubricated for life or relubricable - filled with high-quality grease, with some designs allowing re-greasing
  • Corrosion protection - coatings and special materials to resist moisture, fertilisers, and chemicals
  • Easy mounting - designed for quick fitting and replacement in the field

In simple terms, an agricultural bearing is a tough, well-sealed bearing built to keep farm machinery running reliably in dirty, wet, and demanding conditions

Why are agricultural bearings essential?

Agricultural bearings are essential because farm machinery works in some of the harshest conditions of any equipment. Machines operate in dust, mud, and water, carry heavy and uneven loads, and are often used intensively for short seasons before being stored for months. A standard bearing in these conditions would quickly be contaminated, lose its lubricant, or fail under shock loads. Agricultural bearings are designed specifically to avoid these problems.

Their main benefits are:

  • Excellent contamination protection - advanced seals keep out soil, dust, water, chaff, and crop residue, which are the main causes of bearing failure in farming
  • Long service life - robust designs and high-quality grease help bearings last longer, even in harsh environments
  • Reduced downtime - reliable bearings mean fewer breakdowns during critical periods such as planting and harvest, when every hour counts
  • Low maintenance - many agricultural bearings are sealed and greased for life, reducing he need for regular lubrication
  • Shock and impact resistance - they withstand impacts from stones, rough ground, and heavy loads
  • Misalignment tolerance - self-aligning designs cope with frame flexing, shaft deflection, and mounting errors common in farm equipment
  • Easy installation and replacement - square bore, hex bore, and insert designs allow quick fitting, often in the field
  • Corrosion resistance - protection against moisture, fertilisers, and agricultural chemicals
  • Lower total cost - fewer failures, less maintenance, and less downtime reduce the overall cost of running machinery

These qualities make agricultural bearings important in a wide range of farm machinery, including:

  • Tillage equipment - disc harrows, cultivators, ploughs, subsoilers, and rollers
  • Seeding and planting equipment - seed drills, planters, seed metering units, and press wheels
  • Harvesting machinery - combine harvesters, forage harvesters, headers, and reels
  • Hay and forage equipment - balers, mowers, tedders, rakes, and conditioners
  • Spraying and spreading equipment - sprayers, fertiliser spreaders, and manure spreaders
  • Tractors and trailers - wheel hubs, steering components, power take-off drives, and gearboxes
  • Livestock and handling equipment - feed mixers, conveyors, augers, and elevators
  • Grain handling - augers, conveyors, dryers, and storage equipment

The main types of agricultural bearings

Agricultural bearings are usually grouped by their design, bore shape, and the machines they are used in.

Disc harrow bearings:

  • Square bore disc harrow bearings - fit directly onto square gang shafts, so the bearing turns with the discs without keys or set screws. They have heavy-duty seals and are among the most common agricultural bearings
  • Round bore disc harrow bearings - used on round shafts in some tillage equipment
  • Triple-lip seal designs - use multiple sealing lips and flingers to protect against fine soil and moisture
  • Relubricable designs - fitted with grease fittings for regular re-greasing in heavy-duty conditions

Insert bearings and bearing units:

  • Set screw insert bearings - lock onto the shaft with grub screws, quick to fit and widely used
  • Eccentric collar insert bearings - lock onto the shaft with a circlip suitable for one direction of rotation
  • Adapter sleeve insert bearings - mounted with a tapered sleeve for a secure, concentric fit
  • Square and hex bore insert bearings - slide onto square or hexagonal shafts for direct drive
  • Pillow block units - insert bearings mounted in foot-mounted bearings
  • Flanged units - insert bearings mounted in two-bolt, three-bolt, or four-bolt
  • Pressed steel and polymer housings - lighter, lower–cost housings for lighter duties or corrosive conditions

Hub units:

  • Disc hub units - pre-assembled hubs for tillage and seeding discs, sealed and greased for life
  • Wheel hub units - for trailers, seed drills, sprayers and implements, often based on tapered roller or angular contact ball bearings
  • Bolt-on hub units - supplied ready to bolt onto the machine, making replacement fast

Other agricultural bearing types:

  • Tapered roller bearings - used in wheel hubs, gearboxes and heavy-duty axles
  • Deep groove ball bearings with heavy seals - used in a wide range of drives and rotating parts
  • Spherical plain bearings and rod ends - used in linkages, steering, hydraulic cylinders and pivot points
  • Needle roller bearings - used in gearboxes, universal joints and compact drives
  • Polymer bearings - lightweight, corrosion-resistant bearings for low loads and wet or chemical environments

How to choose the right agricultural bearing?

Choosing the right agricultural bearing means matching it to the machine, the working conditions, and how the equipment will be used and maintained. Work through these points in order:

  • Machine and position - identify exactly where the bearing is used, such as a disc gang, press wheel, baler pick-up, or wheel hub, as each position has different demands
  • Bore shape and size - check whether the shaft is square, hexagonal, or round, and measure it accurately. Square and hex bore sizes are often given in inches
  • Outside dimensions - check the outside diameter, width, and any special features, such as a spherical outer ring, flange, or extended inner ring
  • Loads - consider the size and type of loads, including shock loads from stones and rough ground, and choose heavy-duty design if loads are high
  • Speed - most agricultural bearings work at low to moderate speeds, but check the ratings for faster-running equipment such as fans, mowers, and harvesters
  • Sealing - choose bearings with multi-lip seals, flingers, or extra protection for dusty, muddy, or wet conditions, especially in tillage and harvesting equipment
  • Lubrication - decide between sealed-for-life bearings for low maintenance, or relubricable bearings for very harsh conditions and long service hours
  • Misalignment - choose self-aligning designs, such as insert bearings with spherical outer rings, where frames may flex, or shafts may not be perfectly aligned
  • Mounting method - select the right locking method, such as square bore, set screws, eccentric collar, or adapter sleeve, to suit the shaft and the direction of rotation
  • Housing type - choose cast iron housings for strength, pressed steel for lighter duties, or polymer and stainless steel housings for wet or corrosive conditions
  • Corrosion protection - consider coated, zinc-plated, or stainless steel bearings where fertilisers, chemicals, manure, or washdown are involved
  • Storage and seasonal use - choose bearings with good seals and corrosion protection for machines that are stored for long periods between seasons

FAQ - All you need to know about agricultural bearings

What makes an agricultural bearing different from a standard bearing?

Agricultural bearings have heavier seals, stronger construction, special greases, and features such as square or hex bores, designed to cope with dust, mud, water, shocks, and seasonal use.

Why do many agricultural bearings have square bores?

Square bores let the bearing slide straight onto a square shaft and turn with it, transmitting drive without keys or set screws. This makes mounting simple and secure, especially on disc harrows and planters.

Do agricultural bearings need greasing?

Many are sealed and greased for life, while heavy-duty and relubricable designs should be greased regularly according to the machine manufacturer’s recommendations.

Can I over-grease an agricultural bearing?

Yes, too much grease can damage seals and let contamination in, so it is important to follow the recommended quantity and interval.

Why do agricultural bearings fail?

The most common causes are contamination from soil, dust, and water, lack of lubrication, damaged seals, shock loads, misalignment, corrosion during storage, and incorrect mounting.

Should I replace bearings before the season starts?

It is good practice to inspect bearings before planting and harvest seasons and replace any that are noisy, rough, loose, or leaking grease, as failures during busy periods can be costly.

How can I make my agricultural bearings last longer?

Use bearings with good seals, grease them correctly, clean machines after use, store equipment in a dry place, inspect bearings before each season, and replace worn ones early.

Are hub units better than separate bearings?

Hub units are pre-assembled, sealed, and greased for life, which makes them quick to fit and reliable in harsh conditions. Separate bearings may be cheaper but take longer to fit and maintain.
