Silicone Sealing Rings & Cord
What are silicone sealing rings and cord?
Silicone sealing rings are O-rings made from silicone rubber (VMQ), and silicone cord is the same material supplied as a continuous length for making custom rings and seals. Silicone stays soft and flexible across an exceptionally wide temperature range, from deep cold to high heat, which makes it a popular choice for general sealing where temperatures vary. It also resists ozone, weathering, and ageing, and is a good electrical insulator.
A standard silicone sealing ring or cord has these main features:
- A solid, round cross section, measured as its section diameter
- Silicone rubber (VMQ), which stays flexible from around -55°C up to +225°C
- A hardness rating on the Shore A scale, most commonly 70
- A colour, such as red, white, clear, or black, which is used for identification only.
Silicone is best suited to static seals.
- It keeps its flexibility and sealing force at temperatures where most other rubbers would stiffen or harden.
- It has lower tear and wear resistance than nitrile or FKM, so it is mainly used where the seal does not rub against a moving part.
Silicone cord is supplied as a continuous extruded length, which can be cut and joined to make a seal of any size, or fitted in a groove as a gasket.
Why are silicone sealing rings and cord essential?
Many seals face big swings in temperature, from cold starts to hot running, or work in ovens, freezers, and outdoor equipment. Silicone keeps sealing through all of these, without becoming brittle in the cold or hard in the heat. It also stands up well to sunlight, ozone, and ageing, so it lasts in outdoor and long-term static applications.
Silicone is widely used in hygienic applications, as it is clean, odourless, and easy to keep clean, although food-contact use needs certified material. Because silicone comes in different colours, seals can be colour-coded for easy identification.
Typical applications include:
- Ovens, heaters, and hot air equipment
- Refrigeration and freezer equipment
- Food and drink processing equipment, with certified material
- Medical and laboratory equipment
- Lighting and electrical enclosures
- Static seals in covers, lids, and hatches
- Outdoor equipment exposed to sunlight and weather
- Domestic appliances
The main types of silicone sealing rings and cord
- Silicone O-ring cord - Supplied in metric section sizes, from around 1mm up to 20mm, and in some inch sizes, sold by the metre for making custom rings and seals.
- Silicone O-rings - Ready-made rings in set section sizes and bores, for standard grooves.
- Coloured silicone - Supplied in colours such as red, white, and clear. The colour does not change the performance, but makes seals easy to identify.
- 70 Shore silicone - The most common hardness, which gives a good balance of softness and sealing for most applications.
How to choose the right silicone sealing ring or cord?
- Temperature - Choose silicone where the seal must stay flexible over a very wide temperature range, from around -55°C up to +225°C.
- Static or moving - Silicone is best for static seals. For seals that rub against a moving shaft or piston, a tougher material such as nitrile or FKM is usually better.
- Fluid compatibility - Silicone suits air, water, and many mild chemicals. It is not well suited to fuels and some oils, which can make it swell, so check compatibility before using it with petrol, diesel, or oil.
- Food and hygiene - For food contact, make sure the silicone is supplied with the correct food-grade certification.
- Section and size - Choose a section diameter that suits the groove, and a bore or cord length to suit the seal size.
Essential references and specialised ranges
How the numbering works:
Silicone cord is referenced by its section diameter, colour, and material:
8mm white silicone = 8mm section white silicone cord
Silicone O-rings are referenced by their section diameter and bore, in mm:
4x24 red silicone = 4mm section, 24mm bore
5x8 red silicone = 5mm section, 8mm bore
The outside diameter is the bore plus twice the section, so a 4x24 ring has a 32mm outside diameter.
To work out how much cord is needed for a ring, add the inside diameter to the section diameter, then multiply by 3.14. For example, for a 120mm bore ring in 6mm cord: (120 + 6) x 3.14 = about 396mm of cord.
Suffixes:
VMQ = silicone rubber
70 = hardness on the Shore A scale
RED, WHITE, CLEAR = colour, for identification only
Suffix codes vary between manufacturers, so check the supplier’s catalogue for the exact meaning.
FAQ - All you need to know about silicone sealing rings and cord
What is silicone best used for?
Silicone is best for static seals that need to stay flexible over a wide range of temperatures, especially in hot, cold, or outdoor conditions, and in hygienic applications.
Does the colour of silicone matter?
No. Silicone is made in many colours, such as red, white, clear, and black, but the colour is only for identification and does not change how the seal performs.
Can silicone be used with oil or fuel?
It is not recommended. Fuels and some oils can make silicone swell and lose strength. Use nitrile or FKM for oil and fuel applications.
Is silicone food safe?
Silicone is widely used in food equipment, but food-contact seals need certified material. Check the seal is supplied with the correct certification for your application.
How do I fit a silicone O-ring?
Clean the groove and remove any burrs or sharp edges, as silicone tears more easily than other rubbers. Fit the ring gently into the groove without twisting or overstretching it. If a lubricant is needed, use one that is compatible with silicone, and avoid silicone-based greases, which can make it swell.
How do I identify the size I need?
For an O-ring, measure the section diameter and bore of the old ring, or measure the groove. For cord, measure the section diameter with callipers and work out the length from the groove size.
How can I tell if a silicone seal needs replacing?
Warning signs include:
- Leaks around the seal
- A flattened ring that has lost its round shape
- Tears, nicks, or splits in the rubber
- Swelling or softening from contact with an incompatible fluid
- A failed or split joint on a cord ring
