SKU: WSZC22-JCS
JCS WSZC22 Zinc Plated Steel Hi-Grip Wing Screw Adjustment Range 14-22mm Band Width 13mm
JCS WSZC22 Zinc Plated Steel Hi-Grip Wing Screw Adjustment Range 14-22mm Band Width 13mm
Regular price
$8.66
ex VAT
Regular price
Sale price
$8.66
ex VAT
In stock
Price Break
10+
$7.71
19+
$7.27
29+
$7.19
39+
$7.10
49+
$7.01
74+
$6.93
99+
$6.50
199+
$6.41
249+
$6.32
499+
$6.24
999+
$6.06
Couldn't load pickup availability
Description
Description
Zinc Plated Steel Hi-Grip Wing Screw: Specifically designed for frequently removed hoses, the unique dovetail locking and side lugs of the wing plate ensure excellent sealing and longevity. Used for a wide variety of domestic, automotive and industrial applications, the standard Hi-Grip hose clip is made from mild steel, electroplated, passivated and tested to EN9227. Hi-Grip general-purpose worm drive hose clips are widely regarded for their quality, durability and ability to withstand a great deal of abuse.
- Brand / Quality:
- JCS - High Quality
- Width:
- 13mm
- Min Adjustment Range:
- 14mm
- Max Adjustment Range:
- 22mm
Technical
Technical
| BS No. | 22 |
|---|---|
| Adjustment Range (mm) | 14-22mm |
| Adjustment Range (inch) | 5/8 - 7/8 inch |
| A | 8mm |
| B | 32mm |
| C | 12mm |
| D | 15mm |
| E | 13mm |
| F | 0.9mm |
| G | 24mm |
| Recommended Torque Nm | 5Nm |
| Recommended Torque lb-in | 45lb-in |
