UCPX20 Metric Two Bolt Cast Iron Pillow / Plummer Block Housing with 100mm Bore Insert
UCPX20 Metric Two Bolt Cast Iron Pillow / Plummer Block Housing with 100mm Bore Insert
Regular price
$769.53
ex VAT
Regular price
Sale price
$769.53
ex VAT
In stock
Price Break
10+
$684.88
19+
$646.41
29+
$638.71
39+
$631.01
49+
$623.32
74+
$615.62
99+
$577.15
199+
$569.45
249+
$561.76
499+
$554.06
999+
$538.67
Couldn't load pickup availability
Description
Description
|
UCPX or MP Series Plummer / Pillow Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 100mm
- Style:
- UCPX
- Bolt Hole Centres:
- 337mm
Technical
Technical
| d | 100mm |
|---|---|
| h | 127mm |
| a | 432mm |
| e | 337mm |
| b | 121mm |
| s2 | 64mm |
| s1 | 33mm |
| g | 52mm |
| w | 245mm |
| B1 | 117.5mm |
| n | 49.2mm |
| Bolt Size | 27mm |
| Weight | 31.8 kg |
| Dynamic load | 13300 kgf |
| Static load | 10500 kgf |
