SKU: UCPX.13
UCPX13 Metric Two Bolt Cast Iron Pillow / Plummer Block Housing with 65mm Bore Insert
UCPX13 Metric Two Bolt Cast Iron Pillow / Plummer Block Housing with 65mm Bore Insert
Regular price
$28.14
ex VAT
Regular price
Sale price
$28.14
ex VAT
In stock
Price Break
3+
$13.29
4+
$12.54
9+
$12.39
19+
$12.24
49+
$12.09
99+
$11.94
499+
$11.20
999+
$11.05
1999+
$10.90
2999+
$10.75
4999+
$10.45
Description
Description
|
UCPX or MP Series Plummer / Pillow Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 65mm
- Style:
- UCPX
- Bolt Hole Centres:
- 203mm
Technical
Technical
| d | 65mm |
|---|---|
| h | 76.2mm |
| a | 286mm |
| e | 203mm |
| b | 83mm |
| s2 | 41mm |
| s1 | 25mm |
| g | 32mm |
| w | 154mm |
| B1 | 74.6mm |
| n | 30.2mm |
| Bolt Size | M20 |
| Weight | 7.7 kg |
| Dynamic load | 4870 kgf |
| Static load | 3810 kgf |
