SKU: UCPX.11-36
UCPX11-36 Imperial Two Bolt Cast Iron Pillow / Plummer Block Housing with 2-1/4 inch Bore Insert
UCPX11-36 Imperial Two Bolt Cast Iron Pillow / Plummer Block Housing with 2-1/4 inch Bore Insert
Regular price
$186.24
ex VAT
Regular price
Sale price
$186.24
ex VAT
In stock
Price Break
10+
$165.75
19+
$156.44
29+
$154.58
39+
$152.72
49+
$150.85
74+
$148.99
99+
$139.68
199+
$137.82
249+
$135.96
499+
$134.09
999+
$130.37
Couldn't load pickup availability
Description
Description
|
UCPX or MP Series Plummer / Pillow Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 57.15mm = 2.25 (2-1/4) inch
- Style:
- UCPX
- Bolt Hole Centres:
- 184mm
Technical
Technical
| d | 2-1/4 inch |
|---|---|
| h | 69.8mm |
| a | 260mm |
| e | 184mm |
| b | 79mm |
| s2 | 36mm |
| s1 | 25mm |
| g | 30mm |
| w | 139mm |
| B1 | 65.1mm |
| n | 25.4mm |
| Bolt Size | M20 |
| Weight | 6.3 kg |
| Dynamic load | 4100 kgf |
| Static load | 3150 kgf |
