SKU: UCPX.08-24
UCPX08-24 Imperial Two Bolt Cast Iron Pillow / Plummer Block Housing with 1-1/2 inch Bore Insert
UCPX08-24 Imperial Two Bolt Cast Iron Pillow / Plummer Block Housing with 1-1/2 inch Bore Insert
Regular price
$34.34
ex VAT
Regular price
Sale price
$34.34
ex VAT
Equivalent to: MP1-1/2
In stock
Price Break
3+
$16.22
4+
$15.30
9+
$15.12
19+
$14.94
49+
$14.76
99+
$14.58
499+
$13.67
999+
$13.48
1999+
$13.30
2999+
$13.12
4999+
$12.75
Description
Description
|
UCPX or MP Series Plummer / Pillow Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
Equivalent: MP1-1/2
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 38.1mm = 1.5 (1-1/2) inch
- Style:
- UCPX
- Bolt Hole Centres:
- 156mm
Technical
Technical
| d | 1-1/2 inch |
|---|---|
| h | 58.7mm |
| a | 222mm |
| e | 156mm |
| b | 67mm |
| s2 | 32mm |
| s1 | 20mm |
| g | 26mm |
| w | 113mm |
| B1 | 49.2mm |
| n | 19mm |
| Bolt Size | M16 |
| Weight | 3.5 kg |
| Dynamic load | 2650 kgf |
| Static load | 1910 kgf |
| Rec max speed | 3700 rpm |
