SKU: UCPX.06-20
UCPX06-20 Imperial Two Bolt Cast Iron Pillow / Plummer Block Housing with 1-1/4 inch Bore Insert
UCPX06-20 Imperial Two Bolt Cast Iron Pillow / Plummer Block Housing with 1-1/4 inch Bore Insert
Regular price
$41.31
ex VAT
Regular price
Sale price
$41.31
ex VAT
Equivalent to: MP1-1/4
In stock
Price Break
10+
$36.77
19+
$34.70
29+
$34.29
39+
$33.87
49+
$33.46
74+
$33.05
99+
$30.98
199+
$30.57
249+
$30.16
499+
$29.74
999+
$28.92
Couldn't load pickup availability
Description
Description
|
UCPX or MP Series Plummer / Pillow Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
Equivalent: MP1-1/4
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 31.75mm = 1.25 (1-1/4) inch
- Style:
- UCPX
- Bolt Hole Centres:
- 127mm
Technical
Technical
| d | 1-1/4 inch |
|---|---|
| h | 47.6mm |
| a | 175mm |
| e | 127mm |
| b | 57mm |
| s2 | 25mm |
| s1 | 17mm |
| g | 20mm |
| w | 94mm |
| B1 | 42.9mm |
| n | 17.5mm |
| Bolt Size | M12 |
| Weight | 2 kg |
| Dynamic load | 2010 kgf |
| Static load | 1390 kgf |
| Rec max speed | 4500 rpm |
