SKU: UCFC.215-48
UCFC215-48 Imperial Four Bolt Cast Iron Round Flanged Housing with 3 inch Insert
UCFC215-48 Imperial Four Bolt Cast Iron Round Flanged Housing with 3 inch Insert
Regular price
$357.65
ex VAT
Regular price
Sale price
$357.65
ex VAT
In stock
Price Break
3+
$168.91
4+
$159.42
9+
$157.53
19+
$155.63
49+
$153.73
99+
$151.83
499+
$142.34
999+
$140.45
1999+
$138.55
2999+
$136.65
4999+
$132.85
Description
Description
|
UCFC Series 4 Bolt Round Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the round cast iron housing and includes a grease nipple to facilitate re-lubrication, this style has the benefit of a shouldered back face to facilitate location of the housing prior to fastening in place. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 76.2mm = 3 inch
- Style:
- UCFC
- Pitch Circle Diameter:
- 184.15mm = 184.15 (7-1/4) inch
Technical
Technical
| d | 3 inch |
|---|---|
| a | 8-21/32 inch |
| P | 7-1/4 inch |
| e | 5-1/8 inch |
| i | 45/64 inch |
| L | 2-7/32 inch |
| s | 3/4 inch |
| j | 5/8 inch |
| k | 23/32 inch |
| g | 1-9/16 inch |
| f | 6.2992 inch |
| z | 2-15/32 inch |
| Bi | 3.0630 inch |
| n | 1.3110 inch |
| Bolt Size | 5/8 inch |
| Weight | 7.3 kg |
| Dynamic load | 5190 kgf |
| Static load | 4190 kgf |
