SKU: UCFC.205-15
UCFC205-15 Imperial Four Bolt Cast Iron Round Flanged Housing with 15/16 inch Insert
UCFC205-15 Imperial Four Bolt Cast Iron Round Flanged Housing with 15/16 inch Insert
Regular price
$23.88
ex VAT
Regular price
Sale price
$23.88
ex VAT
In stock
Price Break
3+
$11.27
4+
$10.64
9+
$10.51
19+
$10.39
49+
$10.26
99+
$10.13
499+
$9.50
999+
$9.37
1999+
$9.25
2999+
$9.12
4999+
$8.87
Description
Description
|
UCFC Series 4 Bolt Round Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the round cast iron housing and includes a grease nipple to facilitate re-lubrication, this style has the benefit of a shouldered back face to facilitate location of the housing prior to fastening in place. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 23.81mm = 0.937 (15/16) inch
- Style:
- UCFC
- Pitch Circle Diameter:
- 90.09mm = 90.09 (3-35/64) inch
Technical
Technical
| d | 15/16 inch |
|---|---|
| a | 4-17/32 inch |
| P | 3-35/64 inch |
| e | 2-1/2 inch |
| i | 25/64 inch |
| L | 1-1/16 inch |
| s | 15/32 inch |
| j | 15/64 inch |
| k | 9/32 inch |
| g | 53/64 inch |
| f | 2.7559 inch |
| z | 1-5/32 inch |
| Bi | 1.3386 inch |
| n | 0.5630 inch |
| Bolt Size | 3/8 inch |
| Weight | 0.95 kg |
| Dynamic load | 1100 kgf |
| Static load | 710 kgf |
