SKU: TU40TF-SKF
SKF TU40TF Grub Screw Type Take Up Unit 40mm Bore
SKF TU40TF Grub Screw Type Take Up Unit 40mm Bore
Regular price
$155.42
ex VAT
Regular price
Sale price
$155.42
ex VAT
In stock
Price Break
10+
$138.32
19+
$130.55
29+
$129.00
39+
$127.44
49+
$125.89
74+
$124.34
99+
$116.57
199+
$115.01
249+
$113.46
499+
$111.90
999+
$108.79
Couldn't load pickup availability
Description
Description
|
SKF Y-bearing Take-Up Units with Cast Housing and Grub Screws: This unit consists of a cast housing and an insert bearing. They are typically mounted in take-up frames and connected by an adjustment screw. A grease fitting is provided in the housing for re-lubrication. Benefits: Grease fitting allows re-lubrication |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 40mm
- Style:
- TU
Technical
Technical
| d | 40mm |
|---|---|
| A | 49mm |
| A1 | 17.5mm |
| A2 | 33mm |
| B | 49.2mm |
| D1 | 29mm |
| H | 115mm |
| H1 | 101mm |
| H2 | 83mm |
| L | 145mm |
| L1 | 88mm |
| L2 | 15mm |
| L3 | 83mm |
| N | 50mm |
| N1 | 19mm |
| s1 | 30.2mm |
| Static load Cr | 19 kN |
| Dynamic load Cor | 30.7 kN |
| Fatigue load limit Pu | 0.8 kN |
| Limiting speed | 4800 rpm |
| A5 | 23.5mm |
| Weight | 2.3 kg |
| Compatible end cover | ECY208 |
