SKU: TU3/4TF-SKF
SKF TU3/4TF Grub Screw Type Take Up Unit 3/4 inch Bore
SKF TU3/4TF Grub Screw Type Take Up Unit 3/4 inch Bore
Regular price
$257.07
ex VAT
Regular price
Sale price
$257.07
ex VAT
In stock
Price Break
10+
$228.79
19+
$215.94
29+
$213.37
39+
$210.80
49+
$208.23
74+
$205.66
99+
$192.80
199+
$190.23
249+
$187.66
499+
$185.09
999+
$179.95
Couldn't load pickup availability
Description
Description
|
SKF Y-bearing Take-Up Units with Cast Housing and Grub Screws: This unit consists of a cast housing and an insert bearing. They are typically mounted in take-up frames and connected by an adjustment screw. A grease fitting is provided in the housing for re-lubrication. Benefits: Grease fitting allows re-lubrication |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 19.05mm = 0.75 (3/4) inch
- Style:
- TU
Technical
Technical
| d | 3/4 inch |
|---|---|
| A | 34mm |
| A1 | 13.5mm |
| A2 | 25mm |
| B | 31mm |
| D1 | 19mm |
| H | 92mm |
| H1 | 76mm |
| H2 | 54mm |
| L | 97mm |
| L1 | 62mm |
| L2 | 10mm |
| L3 | 54mm |
| N | 32mm |
| N1 | 16mm |
| s1 | 18.3mm |
| Static load Cr | 6.55 kN |
| Dynamic load Cor | 12.7 kN |
| Fatigue load limit Pu | 0.28 kN |
| Limiting speed | 8500 rpm |
| Weight | 0.73 kg |
