SKU: SSUCF.206-20
SSUCF206-20 Imperial Four Bolt Square Stainless Steel Flange Housing with 1-1/4 inch Bore Stainless Insert
SSUCF206-20 Imperial Four Bolt Square Stainless Steel Flange Housing with 1-1/4 inch Bore Stainless Insert
Regular price
$68.95
ex VAT
Regular price
Sale price
$68.95
ex VAT
In stock
Price Break
3+
$32.57
4+
$30.74
9+
$30.37
19+
$30.00
49+
$29.64
99+
$29.27
499+
$27.44
999+
$27.08
1999+
$26.71
2999+
$26.34
4999+
$25.61
Description
Description
|
UCF or SF Series Stainless Steel 4 Bolt Square Housings: Supplied with a fully sealed stainless steel bearing insert fitted in the stainless steel housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing, food safe and approved, exceptionally strong and durable Note: These bearings will eventually corrode in a marine environment and it is recommended to completely cover with grease or similar protection where practical. Due to the material requirements of these bearings to have a hard-wearing construction, they will be made of a harder form of Stainless Steel, such as 440 or similar, which will be attracted by magnets. Quotations for non-magnetic versions are available upon request. |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 31.75mm = 1.25 (1-1/4) inch
- Style:
- SSUCF
- Bolt Hole Centres:
- 83mm
Technical
Technical
| d | 1-1/4 inch |
|---|---|
| a | 108mm |
| e | 83mm |
| i | 18mm |
| g | 14mm |
| L | 31mm |
| S | 12mm |
| Z | 40.2mm |
| Bi | 38.1mm |
| n | 15.9mm |
| Bolt | 10mm |
| Weight | 1.1 kg |
| Dynamic load | 1520 kgf |
| Static load | 1020 kgf |
