SKU: SSUCF.201-8
SSUCF201-8 Imperial Four Bolt Square Stainless Steel Flange Housing with 1/2 inch Bore Stainless Insert
SSUCF201-8 Imperial Four Bolt Square Stainless Steel Flange Housing with 1/2 inch Bore Stainless Insert
Regular price
$23.67
ex VAT
Regular price
Sale price
$23.67
ex VAT
In stock
Price Break
3+
$11.18
4+
$10.55
9+
$10.42
19+
$10.30
49+
$10.17
99+
$10.05
499+
$9.42
999+
$9.29
1999+
$9.17
2999+
$9.04
4999+
$8.79
Description
Description
|
UCF or SF Series Stainless Steel 4 Bolt Square Housings: Supplied with a fully sealed stainless steel bearing insert fitted in the stainless steel housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing, food safe and approved, exceptionally strong and durable Note: These bearings will eventually corrode in a marine environment and it is recommended to completely cover with grease or similar protection where practical. Due to the material requirements of these bearings to have a hard-wearing construction, they will be made of a harder form of Stainless Steel, such as 440 or similar, which will be attracted by magnets. Quotations for non-magnetic versions are available upon request. |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 12.7mm = 0.5 (1/2) inch
- Style:
- SSUCF
- Bolt Hole Centres:
- 64mm
Technical
Technical
| d | 1/2 inch |
|---|---|
| a | 86mm |
| e | 64mm |
| i | 15mm |
| g | 12mm |
| L | 25.4mm |
| S | 12mm |
| Z | 33.3mm |
| Bi | 31mm |
| n | 12.7mm |
| Bolt | 10mm |
| Weight | 0.63 kg |
| Dynamic load | 1000 kgf |
| Static load | 630 kgf |
