SKU: SNP25-RHP
RHP SNP25 Threaded Base Small Footprint Pillow / Plummer Block and 25mm Bore Grub Screw Full Width Insert
RHP SNP25 Threaded Base Small Footprint Pillow / Plummer Block and 25mm Bore Grub Screw Full Width Insert
Regular price
$85.20
ex VAT
Regular price
Sale price
$85.20
ex VAT
In stock
Price Break
10+
$75.83
19+
$71.57
29+
$70.72
39+
$69.86
49+
$69.01
74+
$68.16
99+
$63.90
199+
$63.05
249+
$62.20
499+
$61.34
999+
$59.64
Couldn't load pickup availability
Description
Description
|
RHP SNP Series Small Footprint Housing Units: Threaded base bearing unit supplied with a sealed full width bearing insert fitted and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft after installation. |
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 25mm
- Style:
- SNP
- Bolt Hole Centres:
- 50.8mm
Technical
Technical
| Bore | 25mm |
|---|---|
| L | 80mm |
| H | 36.5mm |
| H1 | 13.5mm |
| H2 | 71.5mm |
| J | 50.8mm |
| Threads | M10x1.50 |
| A | 36mm |
| A1 | 25mm |
| B | 34.11mm |
| s | 14.32mm |
| d1 | 34.01mm |
| Dynamic load Cr | 14000 N |
| Static load Cor | 7880 N |
| Rec max speed | 6250 rpm |
| Weight | 1.2 kg |
| Insert | <a href="advanced_search_result.php?keywords=1025-25G+insonly">1025-25G Click Here</a> |
| Casting group | 3 |
| Grease nipple thread | 1/4 UNF, 1/4 inch x 28 TPI |
