SKU: SL003_NAK
NAK SL003 Hardened Stainless Sleeve for Shafts 13.89-14.00mm - Allow 7-10 Days
NAK SL003 Hardened Stainless Sleeve for Shafts 13.89-14.00mm - Allow 7-10 Days
Regular price
$41.19
ex VAT
Regular price
Sale price
$41.19
ex VAT
Allow 7-10 Days
Equivalent to: CR99055
In stock
Price Break
10+
$36.66
19+
$34.60
29+
$34.19
39+
$33.78
49+
$33.36
74+
$32.95
99+
$30.89
199+
$30.48
249+
$30.07
499+
$29.66
999+
$28.83
Couldn't load pickup availability
Share this product
Description
Description
NAK Wear-Pro Shaft Protection Sleeves: Wear-Pro Sleeves offer an excellent sealing surface for radial shaft seals whilst reducing costly shaft machining or maintenance. These sleeves can be used anywhere with a radial shaft seal, such as in industrial gearboxes, motors, pumps, reducers, construction, agricultural equipment and automotive parts.
Benefits: Simple and quick installation, cost-effective, high-grade surface
Equivalent: CR99055
- Brand / Quality:
- NAK - High Quality
- Width:
- 9.9mm
- Material:
- SAE 30304 Hardened Stainless
- Shaft Diameter:
- 14mm
- Flange Diameter:
- 19.1mm
Technical
Technical
| Shaft Diameter Range (A) | 13.89-14.00mm |
|---|---|
| Nominal Shaft Diameter (A) | 14mm |
| Flange Diameter (D) | 19.1mm |
| Width on Shaft (X) | 6.3mm |
| Overall Width (Y) | 9.9mm |
| Installation Depth (Z) | 46.5mm |
| Flange Diameter (D) Tolerance | 1.6mm |
| Width on Shaft (X) Tolerance | 0.8mm |
| Overall Width (Y) Tolerance | 0.8mm |
