SKU: NKXR40Z-MB
Major Brand NKXR40Z Needle Roller Thrust Bearing without Cover 40x52x32mm
Major Brand NKXR40Z Needle Roller Thrust Bearing without Cover 40x52x32mm
Regular price
$142.65
ex VAT
Regular price
Sale price
$142.65
ex VAT
In stock
Price Break
10+
$67.37
19+
$63.59
29+
$62.83
39+
$62.07
49+
$61.32
74+
$60.56
99+
$56.78
199+
$56.02
249+
$55.26
499+
$54.50
999+
$52.99
Description
Description
|
Needle Roller / Ball Roller Thrust Combination: Of a none separable design, the outer ring with integral housing washer and integral needle roller cage assembly. Benefits: High thrust loading, easily mounted |
- Brand / Quality:
- Major Brand - High Quality
- Inside Diameter:
- 40mm
- Outside Diameter:
- 52mm
- Width:
- 32mm
Technical
Technical
| Fw | 40mm |
|---|---|
| D | 52mm |
| C | 32mm |
| Dynamic load | 26400 N |
| Static load | 51000 N |
| Axial dynamic load | 43000 N |
| Axial static load | 137000 N |
| Fatigue load limit radial Pu | 6300 N |
| Fatigue load limit axial Pu | 13700 N |
| Min load factor A | 1.5 |
| Speed in grease | 1700 rpm |
| Speed in oil | 2400 rpm |
| C1 | 13mm |
| C2 | 10mm |
| d | 40 |
