SKU: GX40F-SKF
SKF GX40F Maintenance Free Thrust Spherical Plain Bearing 40x105x32mm
SKF GX40F Maintenance Free Thrust Spherical Plain Bearing 40x105x32mm
Regular price
$441.12
ex VAT
Regular price
Sale price
$441.12
ex VAT
Equivalent to: GE40AW GX40T
In stock
Price Break
10+
$392.60
19+
$370.54
29+
$366.13
39+
$361.72
49+
$357.31
74+
$352.90
99+
$330.84
199+
$326.43
249+
$322.02
499+
$317.61
999+
$308.78
Couldn't load pickup availability
Description
Description
SKF Spherical Plain Bearings: Maintenance-free spherical plain thrust bearings with sliding contact surface combination, steel/ PTFE composite. |
Equivalent: GE40AW GX40T
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 40mm
- Outside Diameter:
- 105mm
- Width:
- 32mm
Technical
Technical
| d | 40mm |
|---|---|
| D | 105mm |
| T | 32mm |
| Angle | 6 degree |
| Dynamic load | 173 kN |
| Static load | 275 kN |
| dk | 114mm |
| d1 | 97mm |
| D1 | 59mm |
| B | 27mm |
| C | 21.5mm |
| r1 min | 1mm |
| s | 24.5mm |
| da min | 78mm |
| Da max | 84mm |
| ra max | 1mm |
| Weight | 1.5 kg |
