SKU: FYTJ35TF-SKF
SKF FYTJ35TF Oval Cast Housing with Grub Screw 35mm Insert
SKF FYTJ35TF Oval Cast Housing with Grub Screw 35mm Insert
Regular price
$116.03
ex VAT
Regular price
Sale price
$116.03
ex VAT
In stock
Price Break
10+
$103.27
19+
$97.47
29+
$96.30
39+
$95.14
49+
$93.98
74+
$92.82
99+
$87.02
199+
$85.86
249+
$84.70
499+
$83.54
999+
$81.22
Couldn't load pickup availability
Description
Description
|
SKF Oval Flanged Y-bearing Units with Cast Housing: These units have an oval flange and two holes for attachment bolts. A grease fitting in the housing allows the unit to be re-lubricated. This makes them especially suitable for bearing arrangements that operate under high levels of contamination, high speeds, high temperatures or relatively heavy loads. Benefits: Grease fitting allows re-lubrication |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 35mm
- Style:
- FYTJ
- Bolt Hole Centres:
- 130mm
Technical
Technical
| d | 35mm |
|---|---|
| A1 | 34mm |
| A2 | 16mm |
| B | 42.9mm |
| Da | 88.9mm |
| H | 161mm |
| J | 130mm |
| L | 96mm |
| N | 16mm |
| G | 14mm |
| s1 | 25.4mm |
| T | 44.4mm |
| Static load Cr | 15.3 kN |
| Dynamic load Cor | 25.5 kN |
| Fatigue load limit Pu | 0.655 kN |
| Limiting speed | 5300 rpm |
| Weight | 1.15 kg |
