SKU: FBL-12-DUN
Dunlop FBL-12 Left Hand Imperial Steel / Bronze Lined Maintenance Required Plain Female Rod End 3/4 UNF Thread - Allow 7-10 Days
Dunlop FBL-12 Left Hand Imperial Steel / Bronze Lined Maintenance Required Plain Female Rod End 3/4 UNF Thread - Allow 7-10 Days
Regular price
$54.47
ex VAT
Regular price
Sale price
$54.47
ex VAT
In stock
Price Break
10+
$48.48
19+
$45.75
29+
$45.21
39+
$44.67
49+
$44.12
74+
$43.58
99+
$40.85
199+
$40.31
249+
$39.76
499+
$39.22
999+
$38.13
Couldn't load pickup availability
Description
Description
|
FB Series Maintenance Required Female Rod Ends: The FB series are a standard range of maintenance required general purpose female rod ends suitable for medium heavy industrial/mechanical load applications requiring low friction and good wear resistance, available in both metric and imperial bore and thread sizes. Temperature range -34c to +149c Benefits: Low friction, extended wear life |
- Brand / Quality:
- Dunlop - High Quality
- Thread Size:
- 3/4 UNF
- Thread M / F:
- Female
- Thread Direction:
- Left Hand
- Liner Type:
- Bronze Lined
Technical
Technical
| Bore size | 3/4 inch |
|---|---|
| Thread | 3/4 UNF |
| W | 0.875 inch |
| H | 0.687 inch |
| D | 1.875 inch |
| L1 | 2.875 inch |
| L2 | 1.562 inch |
| O | 0.978 inch |
| AF | 1 inch |
| Static load | 28640 N |
