SKU: 6209-ZZE-NACHI
NACHI 6209ZZE Metal Shielded Deep Groove Ball Bearing 45x85x19mm
NACHI 6209ZZE Metal Shielded Deep Groove Ball Bearing 45x85x19mm
Regular price
$25.42
ex VAT
Regular price
Sale price
$25.42
ex VAT
Equivalent to: 6209ZZ 62092Z 6209.2Z 6209KDD 6209DD 62092ZR 6209FF
In stock
Price Break
5+
$12.01
9+
$11.33
19+
$11.20
29+
$11.06
49+
$10.93
74+
$10.79
99+
$10.12
199+
$9.98
249+
$9.85
499+
$9.71
999+
$9.44
Description
Description
|
NACHI Metal Shielded Deep Groove Ball Bearings: These deep groove ball bearings can sustain radial, axial or composite loads and because of simple design, this bearing type can be produced to provide both high-running accuracy and high-speed operation. This bearing has two steel shields to provide a labyrinth clearance. Benefits: High-running accuracy and high-speed operation. |
Equivalent: 6209ZZ 62092Z 6209.2Z 6209KDD 6209DD 62092ZR 6209FF
- Brand / Quality:
- Nachi - High Quality
- Inside Diameter:
- 45mm
- Outside Diameter:
- 85mm
- Width:
- 19mm
- Seals / Shields:
- Metal Shielded
- Clearance:
- * Standard
Technical
Technical
| Inside Diameter d | 45mm |
|---|---|
| Outside Diameter D | 85mm |
| Width B | 19mm |
| Min radius r | 1.1mm |
| Dynamic load | 32500 kN |
| Static load | 20500 kN |
| Max speed | 7800 rpm |
| da min | 52mm |
| Da max | 78mm |
| ra max | 1mm |
| Weight | 0.407 kg |
