SKU: 53311?EU
53311 Budget Single Thrust Ball Bearing with Spherical Housing Seat U311 55x105x42mm
53311 Budget Single Thrust Ball Bearing with Spherical Housing Seat U311 55x105x42mm
Regular price
$187.05
ex VAT
Regular price
Sale price
$187.05
ex VAT
In stock
Price Break
10+
$88.34
19+
$83.38
29+
$82.39
39+
$81.39
49+
$80.40
74+
$79.41
99+
$74.44
199+
$73.45
249+
$72.46
499+
$71.47
999+
$69.48
Share this product
Description
Description
|
Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. The lower washer has a spherical face to be used with a spherical housing washer. Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment. Benefits: Axial loading, ease of mounting and assembly |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 55mm
- Outside Diameter:
- 105mm
- Width:
- 42mm
Technical
Technical
| d | 55mm |
|---|---|
| D | 105mm |
| H1 | 42mm |
| Dynamic load C | 104 kN |
| Static load Co | 224 kN |
| Fatigue load limit Pu | 8.3 kN |
| Minimum load factor A | 0.26 |
| Reference speed | 2200 rpm |
| Limiting Speed | 3200 rpm |
| Weight | 1.68 kg |
| Seating Washer | U311 |
| d1 | 105mm |
| D1 | 57mm |
| D2 | 80mm |
| D3 | 110mm |
| H | 39.3mm |
| C | 11.5mm |
| R | 80mm |
| s | 30mm |
| r1r2 min | 1.1mm |
| da max | 85mm |
| Da max | 80mm |
| ra max | 1mm |
