SKU: 24B-2-SYNO-10FT-RENOLD
Renold SYNO 24B-2 BS Duplex Roller Chain 1-1/2 inch Pitch - 10 Feet Length
Renold SYNO 24B-2 BS Duplex Roller Chain 1-1/2 inch Pitch - 10 Feet Length
Regular price
$9,687.42
ex VAT
Regular price
Sale price
$9,687.42
ex VAT
Equivalent to: SNX24B-2
In stock
Price Break
10+
$8,621.80
19+
$8,137.43
29+
$8,040.56
39+
$7,943.68
49+
$7,846.81
74+
$7,749.94
99+
$7,265.57
199+
$7,168.69
249+
$7,071.82
499+
$6,974.94
999+
$6,781.19
Couldn't load pickup availability
Description
Description
Renold SYNO Maintenace-free Corrosion-resistant Duplex Chain: Renold Syno Nickel Plated chain is ideal for situations where lubricant is to be avoided. Particularly in hygiene-sensitive applications. With a food industry-approved lubricant contained within its sintered bush, this chain needs no relubricating in practically every environment. The roller coating, unique to Renold, is especially suited to the food industry.
Equivalent: SNX24B-2
- Brand / Quality:
- Renold - High Quality
- Pitch:
- 38.1mm = 1.5 (1-1/2) inch
Technical
Technical
| Pitch (A) | 1.5 inch |
|---|---|
| Pitch (A) | 38.1mm |
| Inside Width min (B) | 25.4mm |
| Roller Diameter max (C) | 25.4mm |
| Plate Height max (D) | 33.4mm |
| Plate Width Inner max (E) | 6.1mm |
| Plate Width Outer max (F) | 5.08mm |
| Pin Diameter max (G) | 14.63mm |
| Pin Length max (H2) | 101.3mm |
| Connecting link extension max (J) | 6.8mm |
| Transverse Pitch nom (K) | 48.36mm |
| ISO606 Tensile strength min | 280000 N |
| Weight | 14.8 kg/m |
