SKU: 20B-2-SYNO-10FT-RENOLD
Renold SYNO 20B-2 BS Duplex Roller Chain 1-1/4 inch Pitch - 10 Feet Length
Renold SYNO 20B-2 BS Duplex Roller Chain 1-1/4 inch Pitch - 10 Feet Length
Regular price
$5,460.24
ex VAT
Regular price
Sale price
$5,460.24
ex VAT
Equivalent to: SNX20B-2
In stock
Price Break
10+
$4,859.61
19+
$4,586.60
29+
$4,532.00
39+
$4,477.40
49+
$4,422.79
74+
$4,368.19
99+
$4,095.18
199+
$4,040.58
249+
$3,985.98
499+
$3,931.37
999+
$3,822.17
Couldn't load pickup availability
Description
Description
Renold SYNO Maintenace-free Corrosion-resistant Duplex Chain: Renold Syno Nickel Plated chain is ideal for situations where lubricant is to be avoided. Particularly in hygiene-sensitive applications. With a food industry-approved lubricant contained within its sintered bush, this chain needs no relubricating in practically every environment. The roller coating, unique to Renold, is especially suited to the food industry.
Equivalent: SNX20B-2
- Brand / Quality:
- Renold - High Quality
- Pitch:
- 31.75mm = 1.25 (1-1/4) inch
Technical
Technical
| Pitch (A) | 1.25 inch |
|---|---|
| Pitch (A) | 31.75mm |
| Inside Width min (B) | 19.56mm |
| Roller Diameter max (C) | 19.05mm |
| Plate Height max (D) | 26.42mm |
| Plate Width Inner max (E) | 4.62mm |
| Plate Width Outer max (F) | 3.61mm |
| Pin Diameter max (G) | 10.19mm |
| Pin Length max (H2) | 76.7mm |
| Connecting link extension max (J) | 2.7mm |
| Transverse Pitch nom (K) | 36.45mm |
| ISO606 Tensile strength min | 170000 N |
| Weight | 7.8 kg/m |
