SKU: 00SS316-JUB
00SS316 316 Stainless Steel HNSS Original Jubilee Clip Adjustment Range 13mm-20mm Band Width 9.9mm
00SS316 316 Stainless Steel HNSS Original Jubilee Clip Adjustment Range 13mm-20mm Band Width 9.9mm
Regular price
$7.44
ex VAT
Regular price
Sale price
$7.44
ex VAT
In stock
Price Break
5+
$7.37
10+
$7.07
20+
$6.92
50+
$6.70
100+
$6.55
500+
$6.18
1000+
$5.21
Couldn't load pickup availability
Description
Description
316 Stainless Steel HNSS Worm Drive Jubilee Clips: The original Jubilee® Clips. Suitable for most day to day needs in the automotive, agricultural, irrigation and farm machinery.
Benefits: Rolled edges provide protection to softer hoses.
- Brand / Quality:
- Jubilee - High Quality
- Width:
- 9.9mm
- Min Adjustment Range:
- 13mm
- Max Adjustment Range:
- 20mm
Technical
Technical
| BS No. | 20 |
|---|---|
| Adjustment Range | 13mm - 20mm |
| Adjustment Range | 1/2 - 3/4 inch |
| Band Width (+/- 0.1) | 9.9mm |
| Band Thickness (+/- 0.1) | 0.762mm |
| Recommended Torque | 3.4Nm |
| Maximum Torque | 4.5Nm |
| Maximum Pressure | 203 Psi |
